Scissor Beam Clamps – BC3-7-J
3-7 inch Scissor Style Beam Clamp

Creating suitable overhead structural suspension points for rigging systems can be difficult so using the building’s own structure can provide more options for the installer. Our pre-engineered scissor beam clamps (BC3-7-J) attach to the building’s beam structure and offer an easy, safe and predictable method of suspension for beam flanges 3″ to 7″. The half inch eye bolt shown to the left (EB-500-75) is sold separately.

Downloads
Standard Features
Specifications
Dimensions
Optional Accessories
Videos

Downloads

Smiley face Datasheet
Smiley face Installation
Smiley facePDF Reader

Standard Features

  • Scissor style clamp gets stronger as the applied weight increases.
  • Infinite adjustments from 3” – 7”
  • Accomadates ½-13 threaded rod or eyebolt for suspension.
  • All domestic fastners.
  • Ideal for permanent and temporary suspensions.

Specifications

SPECIFICATIONSPACKAGE CONTENTS
Materials: Stainless and Galvanized Steel Components1 pc Scissor Beam Clamp
Width: 3” to 7” / 76mm to 178mm1 pc Hardware Kit
Color: GreyEYEBOLT SOLD SEPARATELY
Design Factor: 7:1
WLL: 1130 lbs / 514 Kg. WLL (Vertical)
45 DEG. WL: 620 lbs / 295 Kg.
 90 DEG. WL: 520 lbs / 236 Kg.

Dimensions

Optional Accessories

  • See Wire Rope Datasheet
  • See Shackle Datasheet
